DRFF-520SS | Screw Presenter, Adjustable Rail 1.0-5.2mm
Overview
Introducing the DRFF-520SS Screw Presenter from Delta Regis, a revolutionary solution for your precision screw feeding needs. This state-of-the-art screw presenter boasts an adjustable rail that seamlessly accommodates screw thread diameters ranging from 1.0 to 5.2mm (#0 to #10). Say goodbye to the hassle of multiple rails and embrace the versatility of the DRFF-520SS.
- Adjustable Rail Range: 1.0-5.2mm (#0-#10)
- Feed Control: Three potentiometer adjustments
- Enhanced Durability: Fewer moving parts
- Quiet Operation: Minimized noise
- Manufacturer: Delta Regis
Features & Benefits
- Adjustable Rail: The DRFF-520SS features an innovative adjustable rail that adapts to various screw sizes, eliminating the need for multiple rails and simplifying your assembly process.
- Precise Adjustments: Equipped with three potentiometer adjustments, this screw presenter empowers you with precise control over feed intensity and time, ensuring optimal performance for your specific application.
- Quiet Operation: Experience a peaceful work environment with the DRFF-520SS's quiet operation. This screw presenter operates with minimal noise, creating a more comfortable and productive workspace.
- Enhanced Durability: Engineered with fewer moving parts, the DRFF-520SS ensures exceptional durability, minimizing maintenance requirements and maximizing uptime in your production line.
Technical Specifications
Input Power
100-240VAC
Model
DRFF-520SS
Screw Size
M1.0-M5.2
Manufacturer
Delta Regis
Capacity
200-220 cc
Length (mm)
20mm
SKU
DRFF-520SS
Dimensions
182 x 126 x 147 mm
Output
15 VDC
Weight (lbs)
5.4
Technical Documents
We are always wanting to provide more information! In need of a technical document? Let us know!
