G1A200RH63 | Die Grinder, 3/8 in. - 24 thread, 20000 rpm

(0)No Reviews yet
$573.20
$890
$316.79999999999995
Warning: California Proposition 65 | Trade Regulations Advisory Notice
Item Ships free
Order total must be over $999.99, under 20 lbs and shipping within continental USA

Get your tool under our Flex Warranty!

We will fix it or replace it.

FLEX Warranty keeps your tools safe when manufacturer warranties come up short. Bad luck deserves good coverage.

*Manufacturer warranty only cover you for so long. FLEX Warranty extends and enhances your coverage for up to two years.

Non-Returnable
Spare Parts, Specialty and Custom items are non-returnable and non-refundable
Back

Overview

Ingersoll Rand Die Grinder, 3/8 in. - 24 thread, 20000 rpm

Die Grinder, 3/8 in. - 24 thread, 20000 rpm, model G1A200RH63 by Ingersoll Rand. Available to order online from Flexible Assembly Systems. Do you see this Ingersoll Rand Die Grinder available elsewhere for a lower price? Contact Customer Service about price matching!

G1A200RH63 by Ingersoll Rand

The G1A200RH63 Die Grinder has a free speed of 20000 rpm. The output on this Die Grinder is 3/8 in. - 24 thread

Back

Features & Benefits

  • Ideal for light material removal, cleaning rough castings, deburring parts, cleaning up welds, and other finishing tasks
  • Type 1 Wheel
  • Type 1 Wheel
  • Lightweight, composite housing
Back

Technical Specifications

Model
G1A200RH63
Type
Die Grinder
Manufacturer
Ingersoll Rand
Length (mm)
152.0
Length (In)
6
Free Speed (RPM)
20000
SKU
G1A200RH63
Stock Code
3
UPC
00663024004197
Rated Power (kw)
0.3
Max Free Speed (rpm)
20000
Output
3/8'' - 24 thread, 3'' guard
Exhaust
Rear
Min Hose Size (in)
3/8
Weight (lbs)
1.3
Wheel Size (in)
3
Height Over Spindle (in)
1.9
Side to Center (in)
0.75
Series
G1
Length (in)
6.0
Air Cons. @ Load (cfm)
25
Vibration (m/s2)
10.2, uncertainty: 4.7
Air Inlet NPT (in)
1/4
Rated Power (hp)
0.4
Weight (kg)
0.6
Wheel Size (mm)
75.0
Rated power (hp)
0.40
Min Hose Size (mm)
10
Air Cons. @ Load (L/min)
708
Side to Center (mm)
19
Height Over Spindle (mm)
48
Back

Technical Documents

We are always wanting to provide more information! In need of a technical document? Let us know!

Back

Ratings & Reviews

No reviews available

Be the first to Write a Review
