JT9-708457DXK | JJ-6CSDX, 6'' Deluxe Jointer, 1HP 1PH 115/230V, Quick-Set Knives
Overview
Jet 708457DXK
Jj-6Csdx, 6" Deluxe Jointer, 1Hp 1Ph 115/230V, Quick-Set Knives
If you are looking for a Jointer that squares your wood, every time; look no further. The JET 6"" Long Bed Jointer offers one of the longest working surfaces in its' class. With the addition of an exclusive auto-set quick change knife system you can replace or change all three blades in a fraction of the time other machines take. Make the JET 6"" Long Bed Jointer the next high performance machine for your shop.
Features:- Three high-speed steel quick change knives provide rapid cutting, a superior finish and eliminates the need for a knife setting gauge
- Extra-long heavy-duty cast iron infeed and outfeed tables with precision machined finish
- Built-in rabbeting ledge adds versatility
- Two-way tilting fence with positive stops at 45° and 90° to handle bevel operations
- EXCLUSIVE front-mounted table adjustment handwheels make quick, easy and accurate corrections
- Industrial push-button controls are conveniently placed for easy access
- Built-in dust chute with 4" port connects to your collection system for efficient dust/chip disposal
- Center fence controls are conveniently mounted to allow quick adjustments
- Powerful 1HP motor easily handles the toughest jointing tasks
- Heavy-duty, one-piece steel closed stand includes mounting tabs for increased stability
Technical Specifications
Type
Longbed Jointer
Cutting Capacity - inches
6-1/16 x 1/2
Cutterhead Speed - rpm
6000
Fence Size - inches
32-3/4 x 3-7/8
Table Size - inches
56 x 7-3/8
No. of Knives
3
Rabbeting Capacity - inches
1/2
Rabbeting Ledge - inches
3-1/8 x 8-3/4
Amps
13/6.5
Rated Power - hp
1
Motor Phase
1
Voltage
115/230V
Motor Type
1hp, 1ph, 115/230V
Weight - lbs
237
Technical Documents
We are always wanting to provide more information! In need of a technical document? Let us know!
