M2-500 | Digital Force Gauge, 500 lbF / 250 kgF / 2500 N
Overview
The M2-500 Digital Force Gauge by Mark-10 was designed for basic tension and compression force testing applications up to 500 lbF / 250 kgF / 2500 N. Peak tension and compression readings captured via ±0.5% accuracy and 500 Hz sampling rate. Backlit graphic LCD displays the current, peak tension, or peak compression reading.
Features & Benefits
- Calculates peak tension and compression values
- USB data output of continuous or individual data points
- Ultra-compact, ergonomic housing
- 3 selectable units of measurement
- Configurable default measurement unit and mode
- 500 Hz sampling rate
- Large, backlit graphic display with auto-dimming
- Powered by rechargeable battery or AC adapter
- Reversible housing for alternate load cell orientation
Technical Specifications
Model
M2-500
Permissable Environmental Conditions
40 - 100°F, max. 96% humidity, non-condensating
Overload Protection
200% of full scale
Type
Digital Force Gauge
Manufacturer
Mark-10
Warranty
3 Year Warranty
Capacity
500 lbF / 250 kgF / 2500 N
Load Capacity
500 lbF / 250 kgF / 2500 N
SKU
M2-500
Stock Code
2
Dimensions
3.9 x 2.53 in
Weight (lbs)
0.9
Series
2
Capacity (lbs)
500
Accuracy
±0.5%
Technical Documents
Mark 10 Series 2 Force Gauges Data Sheet (PDF)- Mark 10 Series 2 Force Gauges User Manual (PDF)
- Mark 10 Force Gauge Comparison Chart (PDF)
