TM-394 | Torque Multiplier 5000 Ft-Lb
Min. Qty (1)
Must be purchased in multiples of 1
Order item in multiples of 1, 2, 3, 4, etc.
Overview
Williams TM-394
Torque Multiplier 5000 Ft-Lb
We offer a comprehensive range of reaction bar torque multipliers. The Hydratight Sweeney 390 series requires a low input torque and needle bearings for high efficency, they have an embedded overload protection through sharable output drives (a replacement is supplied with the multiplier), and they have an angle of turn protractor. The 392 and 393 multiplier are packaged in a sturdy carrying case.| Output Capacity | 5,000Ft Lbs |
| Input Capacity | 189 Ft Lbs |
| Torque Ratio | 26:5:1 |
| Input SQ Drive | 1/2” |
| Output SQ Drive | 1 1/2” |
| Accuracy | +/- 5% |
| Overload Protection | Yes |
| Anti Backlash | Yes |
| Head Diameter | 5.62 (143) |
| Height | 8.75 (222) |
| Length | 14.9 (378) |
| Weight | 34 Lbs |
*Note : When selecting a torque multiplier, sufficient torque should be allowed to break out bolts. We suggest 2x tightening torque.
Features & Benefits
- Input torque holding ratchet - holds multiplier in place during torquing
- Needle bearing construction for high efficiency
- Shearable output squares - to protect tool during overload
- Standard reaction plate meets most job applications
