ATGE5CN-G | Digital torque gauge, 5 nCm / 50 mNm / 500 gf cm / 2.8 in oz
Overview
Introducing the Tohnichi ATGE5CN-G Digital Torque Gauge - a cutting-edge solution for measuring torque in low-range applications. Engineered by Tohnichi, this digital torque gauge combines precision, versatility, and ease of use to meet the demands of modern assembly and testing processes.
- Torque Range: 0.01 - 0.05 Nm
- Accuracy: +/-1% F.S.
- Resolution: 0.001 Nm
- Units: Nm, kgfcm, gfcm, ozfin
- Display: LCD with backlight
- Power Supply: 2 AAA batteries (included)
- Dimensions: 120 x 60 x 25 mm
- Weight: 150 g
Features & Benefits
- Unrivaled Accuracy: With a torque range of 0.01 - 0.05 Nm, the ATGE5CN-G delivers exceptional accuracy in low-torque measurements, making it ideal for delicate applications.
- Versatile Configurations: This digital torque gauge offers three convenient configurations - handheld, table-top, or as a torque meter with a testing fixture. This versatility allows for seamless integration into various measurement setups.
- Reliable Overload Protection: A physical stopper prevents accidental overloading, ensuring the gauge's longevity and protecting it from damage caused by excessive force.
- User-Friendly Interface: Equipped with a pull-out display, the ATGE5CN-G provides clear and intuitive readings, enhancing user experience and minimizing errors.
- Wide Application Range: The Tohnichi ATGE5CN-G is ideal for measuring torque in rotating components, click torque of precision machinery, electronic devices, and various assembly components.
Technical Specifications
Model
ATGE5CN-G
Max Torque (Ncm)
5
Type
Digital Torque Gauge
Wrench Type
Digital Torque Gauge
Manufacturer
Tohnichi
SKU
ATGE5CN-G
Stock Code
2
Dimensions
120 x 69 mm
Min Torque (Nm)
0.01
Max Torque (Nm)
0.05
Max Torque (In Oz)
7
Overall Length
120
Series
ATGE-G
Accuracy
±2%
Max Torque (gf cm)
500
Max Torque (mNm)
50
Technical Documents
We are always wanting to provide more information! In need of a technical document? Let us know!
