UAT-40SD | Inline Auto Shut Off Pulse Tool, 4.5 - 8 Nm, 1/4 in. drive
Overview
URYU Inline Auto Shut Off Pulse Tool, 4.5 - 8 Nm, 1/4 in. drive
Inline Auto Shut Off Pulse Tool, 4.5 - 8 Nm, 1/4 in. drive, model# UAT-40SD by URYU; available to order from Flexible Assembly Systems. Do you see this Pulse Tool available elsewhere for a lower price? Contact customer service on price matching!
UAT-40SD by URYU
UAT features patented Auto Relief Technology providing additional control to the application of torque during the pulsing events.
Features:
- Auto Relief eliminates initial spike of torque during a cycle. Highly effective on hard joint applications
- Auto Relief ramps up pressure within the pulse unit resulting in more pulses in less time providing a more efficient and even torque event
Features & Benefits
- UAT features patented Auto Relief Technology providing additional control to the application of torque during pulsing events
- Auto Relief eliminates initial spike of torque during a cycle
- Highly effective on hard joint applications
Technical Specifications
Min Torque - Ft Lbs
3.3
Max Torque - Ft Lbs
5.9
Min Torque - Nm
4.5
Max Torque - Nm
8
Clutch Type
Auto Shut Off
Style
Inline
Drive Size
1/4'' hex
Free Speed - rpm
3300
Type
Pulse Tool
