SL ETV SL21-20-06 | Transducerized Wired Driver, 4-20Nm Angled Torque Driver with 1/4" Square Drive - 465rpm
Overview
Atlas Copco 8433 2009 55
Etv Sl21-20-10, Right Angle Electric Screwdriver, Lever Start, 36-180 In Lbs
transducerized screwdriver, the Tensor SL is a smart, compact and powerful electronic screwdriver that is the ideal tool for achieving zero-fault production in a wide range of low-torque applications. The Tensor SL range is designed to improve your process quality, ensure productivity gains and dramatically cut costs.
Features:- High performance brushless motor with wide torque range gives shorter cycle times and enables faster production.
- All tools have ESD certification, this is you guarantee against damage to electrical components.
- Excellent ergonomics with high power to weight ratio.
- Signal lights ensure detection of incorrectly tightened fasteners.
- Additional blue LED gives increased operator support for example batch OK feedback.
- The configurable function button can be set up for different reverse modes and toggling between different programs
- Configurable buzzer gives tailor made operator feedback.
- Configurable front lights for best visibility.
- Push to start function for fast start.
Technical Specifications
Model
ETV SL21-20-10
Manufacturer
Atlas Copco
Length (mm)
285
Free Speed (RPM)
465
SKU
8433 2009 55
Stock Code
3
Style
Angle Head
Min Torque (In Lb)
36
Max Torque (In Lb)
178
Max Torque (Ft Lb)
180
Min Torque (Nm)
4
Max Torque (Nm)
20
Max Free Speed (rpm)
465
Weight (lbs)
2.5
Technical Documents
We are always wanting to provide more information! In need of a technical document? Let us know!
