18108.B12 | PTM-119-4500-B | 1-1/2 in. Square 4500 Nm Torque Multiplier, Bi-Directional, Stall, 23 rpm

(0)No Reviews yet
$8,604.33
$9928
$1323.67
Warning: California Proposition 65 | Trade Regulations Advisory Notice
Item Ships free
Order total must be over $999.99, under 20 lbs and shipping within continental USA

Get your tool under our Flex Warranty!

We will fix it or replace it.

FLEX Warranty keeps your tools safe when manufacturer warranties come up short. Bad luck deserves good coverage.

*Manufacturer warranty only cover you for so long. FLEX Warranty extends and enhances your coverage for up to two years.

Non-Returnable
Spare Parts, Specialty and Custom items are non-returnable and non-refundable
Back

Overview

Norbar 1-1/2 in. Square 4500 Nm Torque Multiplier, Bi-Directional, Stall, 23 rpm

18108.B12

1-1/2 in. Square 4500 Nm Torque Multiplier, Bi-Directional, Stall, 23 rpm by Norbar. Available to order from Flexible Assembly.com. Do you see this Torque Multiplier online at a lower price? Contact Customer Service to price match!

Back

Features & Benefits

  • Efficient air motor
  • Exceptionally low vibration levels
  • Light weight design
  • Very quiet operation
Back

Technical Specifications

Model
PTM-119-4500-B
Type
Torque Multiplier
Drive size
1-1/2'' square
Manufacturer
Norbar
Length (mm)
456
Min Torque (Ft Lb)
660
Free Speed (RPM)
23
SKU
NOR18108.B12
Style
Pistol Grip
Max Torque (Ft Lb)
3300
Min Torque (Nm)
900
Max Torque (Nm)
4500
Weight (lbs)
27.5
Series
PTM-119
Drive Type
1-1/2 in. Square
Weight (kg)
12.5
