730/80 | Click-Type Service Torque Wrench,3/8'' square, in lbs
Overview
The Stahlwille 730/80 is a service-oriented click-type torque wrench engineered for high precision, ease of use, and long-term reliability. Designed with a unique mechanism that only applies load while torque is being delivered, the 730 eliminates the need for manual resetting to zero, reducing wear and increasing durability.
Supporting interchangeable insert heads, the Mankoskop 730 is flexible across a wide range of fasteners and applications. The dual-scale display features a built-in magnifier for high readability, and the optimized convex handle promotes strain-free, ergonomic operation—even in extended use.
The Mankoskop 730 is suitable for both clockwise and anticlockwise torque tightening by reversing the insert head. It’s also engineered to resist damage from overload or reverse force beyond the trigger point, protecting the mechanism from misuse. Delivered with full DIN EN ISO 6789-2:2017 certification, this tool can be recalibrated using Stahlwille’s PerfectControl system—without needing disassembly.
Features & Benefits
- Precision Measurement: ±4% deviation in torque display per DIN EN ISO 6789-2:2017 certification.
- Dual Direction Tightening: Handles both clockwise and anticlockwise torque applications.
- Clear Torque Readout: Comparative scale in in·lb with sliding cursor for quick torque reference.
- Secure Bit Handling: 1/4" internal hex drive securely holds inserts and adaptors (DIN 3126/ISO 1173 compliant).
- Accessory Compatible: Easily attach 1/4" sockets using optional adaptor; 3115 (sold separately).
Technical Specifications
Technical Documents
We are always wanting to provide more information! In need of a technical document? Let us know!
Frequently Asked Questions
What makes the 730/80 different from traditional torque wrenches?
Can it be used for both clockwise and counterclockwise torque applications?
Yes. Simply rotate the interchangeable insert head to switch between directions.
Is the 730/80 compatible with standard insert tools?
Yes, the 730/80 supports standard Stahlwille insert tools (interchangeable heads), including open-end, ring, and square drives.
Does the 730/80 require disassembly for recalibration?
No. The 730/80 can be recalibrated using the Stahlwille PerfectControl system without disassembly, streamlining maintenance.
