SVAC9-2 | VACUUM OVEN, 9.3 CU FT, 230V

Model VPX9-2, Large Capacity Vacuum Oven, Three Shelves, 9 Cu.Ft. (also: model 1495D)
The Waltow 981 temperature controller, programmable and microprocessor-based, offers multiple ramp and soak capabilities, including storing and running up to 24 temperature profiles. The controls are easily adjustable and the control panel is user friendly. A digital vacuum gauge shows chamber vacuum level in measurements of Torr and m/Torr. The display range is 760 Torr down to 0 mil Torr. A secondary independent high limit controller provides overtemperature safety protection.
The oven chamber is wrapped in high temperature insulation which aids overall performance and promotes energy efficiency. Powder coat construction, true vacuum valves and cross-flow ventilation through the oven chamber enhance total performance. The vacuum oven is secured to a ruggedly constructed mobile stand to create a vacuum pump at the base. Although the oven is not supplied with a vacuum pump, all vacuum plumbing and KF25 connections are provided.
SHEL LAB Vacuum Ovens are unparalleled in the quality of their construction. Features include:

• Large 9 Cu.Ft. Capacity
• Ramp and Soak Controller
• Stainless Steel Interior
• KF40 Fitting Included
• Built in Vacuum Pump Mount
• 24 Month Limited Warranty
