JT9-708597K | JSG-96CS, 6''x48'' Belt / 9'' Disc Sander, Closed Stand, 3/4HP 1PH 115V

(0)No Reviews yet
$1,249.99
$1535
$285.01
Item Ships free
Order total must be over $999.99, under 20 lbs and shipping within continental USA

Get your tool under our Flex Warranty!

We will fix it or replace it.

FLEX Warranty keeps your tools safe when manufacturer warranties come up short. Bad luck deserves good coverage.

*Manufacturer warranty only cover you for so long. FLEX Warranty extends and enhances your coverage for up to two years.

Non-Returnable
Spare Parts, Specialty and Custom items are non-returnable and non-refundable

Overview

Jet 708597K

Jsg-96Cs, 6"X48" Belt / 9" Disc Sander, Closed Stand, 3/4Hp 1Ph 115V

The unique JSG-96CS Sander combines a 9" disc and 6" x 48" belt for workshop versatility. While small and compact, the JSG-96 offers industrial 3/4 HP power while taking up a small footprint in your shop. A quick-release belt tension lever makes belt changes fast and easy while a quick-lock dust cover allows fast disc changes.

Features:
  • Large cast iron table has preset stops at 90° and 45° to let you use the belt sander vertically, horizontally or anywhere in between
  • EXCLUSIVE dual thumbscrew belt tracking adjustment locks to keep belt on track during use
  • Graphite covered steel platen runs cooler increasing machine and belt life
  • Specially designed belt guard allows full use of the 6" belt width and length
  • Drive drum is rubber-coated for a better grip on the sanding belt resulting in less slippage
  • Tracking adjustment knob with quick-lock handle keeps belt on track during use
  • Quick-release belt tension lever makes belt changes fast and easy
  • Quick-lock dust cover allows fast disc changes
  • Single 4" dust port on the back of the base collects dust effectively from both the belt and disc
  • Powerful 3/4HP motor easily handles the toughest sanding operations
  • Built-in handles for easier portability
  • One-piece formed steel heavy-duty closed stand provides additional support and additional storage for abrasives
  • Integrated locking wheels for easy mobility

Technical Specifications

Belt Size - inches
48 x 6
Type
Disc Sander, closed stand
Belt Speed - sfpm
2258
Belt Table Size - inches
11 x 5-1/2
Disc Diameter - inches
9
Disc Speed - rpm
1725
Disc Table Size
12 x 7-1/2
Stand Type
Closed
Amps
11
Rated Power - hp
.75
Motor Phase
1
Voltage
115V
Motor Type
.75hp, 1ph, 115V
Weight - lbs
160
